Janju province pure production of jdl-5000n rubber detachment electric pull tester

Panel model: jdl-5000n

IiiJanju province pure production of jdl-5000n rubber detachment electric pull testerPlatform description:

Numerical electro-thrust test machines are used mainly to test conventional mechanic performance indicators for various types of rubber, plastics, textiles, leather, metals, non-metals and composite materials. Full numerical amplification, collection, closed loop control is used to make displays stable, accurate and user-friendly. The mainframe uses brand electric and speed-reducing systems, precise speed-reducing machines, fine wire bars, having the characteristics of smoothing, low noise, high speed accuracy, wide speed range and long service life; the liquid crystal shows the test process in real time, and the machine selects different sets to perform the mechanical tests of compression, bending, stripping, pull, tearing, piercing, stretching, etc., as requested by the client. It is small, easy to use and simple to operate; it has limits, auto-overload protection, auto-cut-off features, etc. Large screen liquid crystals are used to display load values, bit shifts, deformation values, test velocity and test curves. The test results can be automatically saved and, after the test, the test curve can be redirected. Standard gb/t16491-1996。

IvJanju province pure production of jdl-5000n rubber detachment electric pull testerTechnical parameters:

1. Range: 50n-300kn (customer selection)

2. Strength precision: 0. 5% of the indicative value internal

3. Test speed: 0. 1-500 mm/min (which may also be determined at the time of purchase)

4. Range: 800 mm (additional arrangements may be made at the client's particular request)

5 theoretical accuracy: within > 0. 5% of the indicative value。

Power: ac220v ±5% 50hz

VJanju province pure production of jdl-5000n rubber detachment electric pull testerCharacteristics

1. Automatic zero: automatic zero before testing

Automatic rate of transformation: test velocity during the course of the test can be run at an advance rate or can be changed as required

3. Logo verification: accurate marking of the system's achievable power values

Automatic storage: automatic storage of test conditions, test results, spacing, etc.

5. Method of display: colour crystal display screens, loads, stretches, speeds, etc. Can be displayed in due course during the testing process, and the client can also choose a mini-heat-sensitive printer, post-test force values, bit shifting values, stretch strength, stretch extension, etc.

6. Limit protection: automatic limit protection

7. A multi-purpose machine: a multi-purpose machine can be achieved by adding sensors and kits of different specifications and expanding the range of measurements。



Our company also produces electro-thrusts, material test machines, recycle test machines, environmental test machines, shock testers, rubber testers, plastic test machines, rubber-like cryogenic test machines, grinding testers, melting indexors, flush machines and density meters, thickness gauges, sulfur transformers, etc., and welcomes a wide selection of customers。
