I. Name of platform: material tester
Ii. Panel model: wdl-10kn
IiiWdl-10kn panel breaker strength tester, pure microprocessor, janju provincePlatform description:
The micromechanical controlled electronic material tester uses a luxury test software interface to achieve control models such as fixed speed, positioning shift and multiple control models that meet different test requirements. Overloading of emergency shut-off units. It covers standard norms like gb, astm, jis, bs... Multilingual random switching: credit, credit chinese, english. Win-xp test software computer screen display. Rs232. Transfer. Provides user-sets for all test data and repeats input data at a time. Each length, unit of force, display of digits is dynamically interchangeable. Graphical curve scale automation (auto scale) allows graphics to be displayed on scale. And you can switch the real-time graphic dynamic from the test. An extension of the weight-place, weight-time, place-time, stress-response weight-2 points. Test results can be exported in the form of data in excel, text, HTML etc. The test ends with automatic archiving, manual archiving, completion of the automatic search force, upper and lower yield strength, stretch strength, bend strength, fixed stretch strength, 300 per cent stretch strength, elasticity modulus, extension rate, detached area size, average, ring-strength test, piercing strength, etc. On the basis of the customer's request, the machine selects different sets for testing such materials as rubber, plastics, leather, metals, nylons, fabrics, stretching, compression, bending, shearing, glue, stripping, tearing, etc。
IvWdl-10kn panel breaker strength tester, pure microprocessor, janju provinceTechnical parameters:
1 range: 50n-300kn (customer selection)
2. Strength precision: within > 0. 5 per cent of the indicative value
3. Test speed: 0. 01 mm/min-500 mm/min; special test speed may also be tailored to client needs)
4. Effective stretch distance: 800 mm; (without handlers, special walk space may be customized to client needs)
5 theoretical accuracy of the migration measure: > 0. 3% of the indicative value
6. Small force values: 0. 001 n
7 print function: hard power after the test can be printed, place change value, stretch strength, stretch extension, etc.
Power voltage: ac220v ± 5% 50hz
Software systems: software packages under windows 2000/xp platform in chinese
VWdl-10kn panel breaker strength tester, pure microprocessor, janju provinceCharacteristics:
1 quantification mode: full-scale, unsegregated and equivalent to seven
High resolution: resolution > 250,000 yards
Auto-storage: test conditions, test results, automatic storage of space
4. Automatic return: automatic return to initial test location
Automatic calibration: loads, stretches, can be automatically marked at the standard values added
6. Pluralistic controls: control methods such as shift, load, stress, stretch, adaptation, etc.
7. Manual devices: multi-dimensional operating units that make it easier to adjust the crosses
Continuous testing: once a set of test parameters have been set, they may be tested continuously
9 wide range: multiple sensors can be simultaneously marked to expand the scope of the test
Data editing: once the test has been completed, the data can be edited with the mouse on the test curve
11, multiple curves: multiple curves such as the choice of stress-resilient, force-extension, force-temporal, strength-temporal, and time, with three different curves on the same graphic
12, curve comparison: curves of the same sample can be contrasted
13, graphical analysis: any point on the test curve may be partially amplified
Report editing: different reporting formats can be exported according to user needs
15. Multiple protections: systems are protected by overflow, overpressure, hypervelocity, underflow, underpressure, etc.; cross-curricular journeys are protected by triple control and software limits; load sensors are protected by excess range; emergency brakes can be performed in case of emergency
Dynamic display: the load, stretch, position shift and selected test curves are shown on the master screen as the tests proceed
17, peak retention: throughout the testing, the large values of the test items are always shown on the screen window following the test
18, easy-to-zero: load, stretch, position shift, one key to move zero manually, with automatic zeroing at the start of the test
19. A multi-purpose machine: a multi-purpose machine can be achieved by increasing the range of measurements by adding sensors and traps of different specifications。
Our company also produces electro-thrusts, material test machines, recycle test machines, environmental test machines, shock testers, rubber testers, plastic test machines, rubber-like cryogenic test machines, grinding testers, melting indexors, flush machines and density meters, thickness gauges, sulfur transformers, etc., and welcomes a wide selection of customers。
