Ata-m2 power amplifier profile
Ata-m2 is an ideal single-channel power amplifier. Maximum output 175 vrms voltage, 200 va power, driver 0 ~ 100% resistance or non-obstructive load. The output resists matching multiple slots and the client can adjust according to the test requirements。
Input
Single-end input, enter as the bc interface。
Output
The output resists matching multiple voltage slots and the client can adjust the percentage of the voltage (0~100%) to the corresponding slot according to the test needs. The equipment is overheating, overloaded, and the lcd panel displays the current state of protection before re-exporting after failure。
Display liquid crystal panel
The ata-m2 power amplifier is shown on a liquid crystal screen, the state of the equipment and the dynamics of the parameters are shown, the operational interface is clear and easy to understand。
Monitor
Output current monitor: 100 mv/a
Output voltage monitor: 10 mv/v
The output monitor port is the bnc interface and can be connected directly to the oscilloscope for real-time monitoring。
