Plastic tubing hammer shock tester - plastic tubing hammer-type shock tester - tube resistant external shock performance test - tube shock test
I. Name of platform: hammer impact tester
Ii. Panel model: zwg-0309
IiiPlastic tube hammer shock testerPlatform description:
This machine is used for impact tests of non-metal materials or products such as plastics, glass, ceramics, etc., and is a test instrument for evaluating material impact performance. The altitude rises and drops are shown on a ruler, intuitively accurate, and automatically prevents secondary shocks, consistent with
Zbn 72026 technical conditions for the hammer impact tester
Gb/t1452 thermoplastic plastics tube test method for external shock tolerance, clockwise rotation
Gb/t14153 " general principles for the test method for hard-standing plastics "
Gb612 test methods for the resilient performance of thermoplastic plastic tube and pipes (stamp act)
Gb/t1002. 1 “strategic pvc-u) tubes for water”
Gb/t1002. 3 “drained sewerage, wastewater (pvc-u) tubes”
Gb/t13664 “putting pvc-u) tubes in low-pressure irrigation with thin walls”
Gb11548 " hard plastic sheet resistance to shock performance test method "
Jb/t5125 agricultural hard clusters
Gb/t8814, " hard pvc-type door, window frame " and
Standard requirements such as gb/t5836. 1 " construction drainage for hard cubes " 。
IvPlastic tube hammer shock testerTechnical parameters:
1. Hammer mass: 0. 5kg, 0. 8kg, 1. 0kg, 1. 25kg, 1. 6kg, 2. 0kg, 2. 5k. 2kg, 4. 0kg, 5. 0kg, 6. 3kg, 8. 0kg, 10. 0kg, 12. 5kg, 16. 0kg (selection)
2. Hammerhead arc radius: r5mm, r10mm, r25mm, r30mm, r50mm (selection)
3. Station schedule: 0-400 mm
4. Sample diameter: 10-400 mm
5. Impact height: 0-2000mm
6. Impact centre and packaging centre deviation: not more than 2 mm
7. Tray type: 120 °v or portable supports, pegs board
Power supply: ac220v (1)(10%)50hz
9. Outer dimensions (long x wide x high): 750 mm*550 mm*3500 mm
Our company also produces electro-thrusts, material test machines, recycle test machines, environmental test machines, shock testers, rubber testers, plastic test machines, rubber-like cryogenic test machines, grinding testers, melting indexors, flush machines and density meters, thickness gauges, sulfur transformers, etc., and welcomes a wide selection of customers。
