I. Name of platform: tube resistant tester
Panel model: dc-0313
IiiPlastic tube instantaneous bursting and pressure resistant testerPlatform description:
This machine is used to determine the pressure values of thermal plastic tubes, composite tubes (e. G., pp-r, pp-b, pp-a, pe, pe-x, pvc, pvc-u, pvc-c and aluminium plastic tubes) at the time or instant bursting at constant internal pressure and constant temperature over a long period of time. Compliance with the gb/t6111 method for internal pressure tolerance testing of thermoplastic tubes for fluid transport, gb/t15560. The tube resistant tester uses a nordic technical structure, pressurizes a non-gas-free hydraulic (media for water) system, the high-voltage pump uses the us 2525 three-plug 25mpa high-voltage pump, the electrical control system uses taiwan-based tectonic plc (microprogrammable controller), the operating part uses micromachine control, the operator sets instructions through the monitor and, following the plc central cluster controller, the plc controllers communicates the control information continuously to the various implementing components, while the implementing components feed back the results back to the plc controllers to the monitors, thus achieving direction and execution, the implementation and transfer of information on the commands, the setting of test parameters on the displayer, allowing real-time display of test pressure, test time, test pressure and test time curves; and the real-time display of test temperature on the temperator. Plc central cluster control for smart unguarded testing. Pressure sensors sample at 0. 3 seconds, increasing the overall signal response speed, control accuracy and reliability for long-term work. It is also capable of achieving independent control of the test pressure, test time, such as when a road sample completes the test, breaks or leaks without prejudice to the continuation of the test on the other routes, so that it can also be tested on pipes with different specifications, models and materials; it has electrical failure protection, and the test data are automatically restored and the original test data are maintained when the power outages, and the failure to do so occurs。
IvPlastic tube instantaneous bursting and pressure resistant testerTechnical parameters:
It consists mainly of pressure control systems (high pressure pumps, mainframes), medium incubators, temperature control systems, and packagings。
(i) independent control of test pressure, test time on route iii
2. Pressure range: 0-16. 00 mpa (arbitrary setting)
3. High pressure pumps
1) pressure: 165-238 bar
2) traffic: 8. 3-11 l/min
3) rotation speed: 750rpm/min
4) three cylinders in diameter: 12 mm
4. Controlled pressure accuracy: +2% of the maximum test pressure value and -1% of the lower test pressure value
5. Pressure value resolution: 0. 01 mpa
6. Pressure transmitter: test pressure sampling frequency 0. 3 seconds
Temperature range: room temperature ~95°c (at any rate set)
8. Controlled temperature accuracy: ± 1 °c
Timescale: 0~9999h
10. Timing accuracy: 1 per cent
11. Power: 10 kw
12. Power: 380vac/220vac (triple-by-five)
13. Host external size: long x width x high 600 mm x 650 mm x 1800 mm
