Functional characteristics:
Support for the 8bit/10bit double-road vds (1920*1080) high-resolution display
Use of 3-d digital combo filters and 3-d noise reduction techniques
Real colour osd, humanized menu
Supporting digital audio output, internal horn 10w*2
Using the mstar ace-5 automatic colour and image enhancement engine to improve contrasting, detail, colour, edge, etc.
Application of programmable 12-bit rgb gamma correction techniques
A line-by-line campaign to compensate for the disease, and to improve the sawing and ambiguity along the motion picture
(b) full-functional infrared remote control and ease of operation
(b) the permanent use of liquid crystal screens is protected by automatic debris removal
Show category ed backlight
Screen size, 43 inches
Point distance 0. 4902 mm x 0. 4902 mm
Large resolution 1920X1080
Good working resolution 1920X1080@60hz
Brightness 380cd/m2
Contrast 1200:1
Response time 8ms
Colour 16. 7m
Visual area 945. 2 mm x 533. 4 mm
Visual angle 178 degrees, vertical 178o
Interface dvi input interface 1
Vga input interface 1
Hdmi input interface 1
Bnc output interface 1
Audio input interface 1
Rs 232-in 1
Rs 232-out 1
Speaker 10w*2
Power ac100v - 240v 50/60hz
Work, 65w
Stand-by power consumption
Working temperature 0°c - 40°c
Work humidity 10% - 90%
Storage temperature -10°c -55°c
Storage humidity 10% - 90%
The bottom wall-size drawings, not the bottom seat. People
Nudity size (w*h*d) 968. 2 * 565. 2 * 78. 5 mm
Packaging dimensions (w*h*d) (mm) 1200*785*210mm (paperbox)
Gross weight 12. 8 kg ± 1. 5 kg (paperbox)
Net weight 9. 1 kg ± 1. 5 kg
Standard configuration, remote control, 1
Battery 2
Power line 1
Use instructions 1
Qualifications/maintenance cards 1
*note: the above parameters may differ from the specific product, depending on the object or the local sales personnel。
