Schreiber-messtechnik sensor with reverted spring integration or external electronic component
Measurement path length 100 m
Shell ø 10 to 25 mm
Product list
Sm20 Ø10mm,8mm measurement path, external electronic component, small design
Sm21 Ø10 mm, 20 mm measurement range, external electronic components, small design
Sm22 |8/10mm, 20mm measurement path, external electronic component, fine probe
Sm224 | 8mm, 20mm process, external electronic component, probe with precise roller track
Sm24 | m12x1,15mm measurement range, external electronic component, shell m24x1
Sm26 Ø12mm 200mm measurement range, external electronic component, also as a button
Sm30 | m30x1,15mm measurement range, integrated electronic components, shell m30x1. 5
Sm31 | m30x1,15mm measurement path, integrated electronic components, programmable
Sm32 25x25mm, 15mm process, integrated electronic components, square shell
Sm33 25x25mm, 15mm measurement range, integrated electronic components, square shell, programmable
Sm34 |10mm only, measured range 20mm, integrated electronic components, output signal 0(4)-20ma, 0-(5)10vdc
Sm40 Ø25mm,200mm measurement range, integrated electronic components, also as buttons
Sensor of sensor of sensor
Nife rotors rotate through two half-wires of differential strangulation。
The corresponding position of the rotor results in the corresponding electron distribution of the coil in two and a half。
External or integrated electronic devices convert position to an angle proportional signal。
Product list
Sensor of sensor of sensor
Sm60 |36. 5mm, external electronic equipment, synchronization of french
Sm61 |36. 5mm, integrated electronic components, synchronized french
Sm62 Ø58mm, integrated electronic component, standard encoder
