Forklifts, including wheels, towing beams, racks, hydraulic devices, shovels with shovels, stows and stows, which are characterized by shovels with shovels and stabbings, are made up of fights, slide barriers, steering barriers, blades and machetes
Performance parameters
1 engine power: 250 kw (335hp)
Rating speed: 2100r/min
2. Forkling capacity: 12 cubic metres stacked
Forklift width (cutting width): 1980mm
Maximum earth cut depth: 350 mm
Maximum excavation: 22100 kg
3. Quality of complete operation: 31000 kg
Quota weight: 2000kg
Maximum speed of movement: 25. 2 km/h (forward 4 and back 3)
Minimum turn radius: 5,000 mm
Mounting capacity: 30 per cent
5. Maximum distance: 573 mm
6. Maximum pressure for hydraulic system work: 21mpa
7. Tracks: single teeth
Nodal distance: 228. 6 mm
Width: 710 mm
Ground comparison pressure: 0. 06 mpa
8 the outer dimension: 6730 x width 3480 x height 4215 mm
Transport dimensions: 6730 x width 3480 x height 3445 mm
Operational procedures
One person at a four-step operation:
Pine soil - loading - transport - dumping
1 pine earth
The shovels are set to the desired depth and the earth is torn up。
2. Loading
Forklifts can be carried at distances ranging from 25 to 40 metres depending on the size of the machine. This process takes 24 to 40 seconds。
3. Transport
A shovel full of earth. The machine proceeded at 20 kilometres per hour to the site of the earth's dumping。
4. Dumping
