Compressed airZeniumPrecision filter filter coreXf9-80 xf7-80 xf5-80
The national product card filters are the original brand filters produced by our division. The filters are based on the original german import of the hv product and are registered as the “gorgeous” card. The other brands covered by the company are not brand-specific, but are used as product model references and customer selection comparisons. Import cores and filters are imported in their original form and are marked against forgery. Our department has long produced various types of compressed air filter filter filter cores for major companies in the country. 5
Hangzhou jiaqiu produces precision filter cores, imports hv filters certified according to fda standards for third-party testing, and filter effects certified for third-party testing。
Leach cores are used to remove liquid water, oil fog, solid particles and aroma from compressed air to achieve different air quality j。
The recommended replacement period: usually 4000 ~ 8000 hours (about half to one year), depending on the state of the front end air press, ambient air quality and frequency of use。
Replacement sign: when the pressure range indicator on the filter becomes red (usually over 0. 7 bar or 0. 5 bar), b must be replaced immediately, otherwise it will cause energy consumption to increase or filter failure
C
Main function: to remove large quantities of liquid water, oil droplets and large solid particles from compressed air。
Filter accuracy: solid particles above 3 micrometres (μm) can normally be filtered。
Residual oil content: fog content in treated compressed air is usually 5 ppm (mg/m3)。
Applying scenery: typically used as a rough filter for the lead road to protect follow-up equipment。
T
Main function: to remove smaller solid particles, oil fog and water vapour。
Filter precision: solid particles above 1 micrometre (μm) can normally be filtered。
Residual oil content: the oil mist content in treated compressed air is usually ≤1 ppm (mg/m3)。
Application scenario: for aerodynamic tools, pre-treatment before general spray。
A
Main function: to remove j fine oil mist, water vapour and microdust and to meet j high air quality standards。
Filter precision: solid particles above 0. 01 μm can normally be filtered。
Residual oil content: the oil mist content in treated compressed air is usually ≤ 0. 01 ppm (mg/m3)。
Application scenario: for precision instrumentation, air-respiration system, g precision spray, food medicine, etc。
