Janju province pure production of zwy-0318 thermal deformation voca soften point temperator

I. Name of platform: thermal deformation voca temperometer

Ii. Panel model: zwy-0318

IiiJanju province pure production of zwy-0318 thermal deformation voca soften point temperatorPlatform description:

Thermal deformation and vika softening point determination are used mainly for non-metal materials (e. G. Plastics, rubber, nylons, electrical insulation materials, etc.). It is an ideal testing tool for chemical enterprises, scientific institutions, universities, etc. This instrument meets the requirements of standards iso75-1974, iso306-1974, gb/t1633-2000, gb/t1634, gb/t8802-2001, which allow real-time display, temperature control, measurement, etc. The machine could also be equipped with a computer printer, controlled by the pc for the entire experimental operation, using the windows 98/me/2000/xp operating system platform, graphical software interfaces, flexible data processing and modular vb language programming。

IvJanju province pure production of zwy-0318 thermal deformation voca soften point temperatorTechnical parameters:

Temperature control range: rt+10 ~300°c

Warm rate: 50°c/h, 120°c/h

3. Temperature measurement error: +0. 5°c

4. Temperature control error: +0. 5°c/6 minutes (vica test), +1°c/6min (thermal deformation test)

5. Deformation measurement range: 5mm

6. Distinction measurement error: +0. 01 mm

7. Number of sample racks: 3 (specified additional requirements)

8. Heated media: +silica oil (less than 200 ths and more than 300°c flash point)

9. Heating power: 3kw

10. Cooling mode: air cooling above 150°c

Water cooling under 150°c

Main power source: 220v+10%, 4kw, 15hz

12. Sub-power: 220v+10%, 1kw, 50hz



Janju province pure production of zwy-0318 thermal deformation vica soften point temperatorOur company also produces electro-thrusts, material test machines, recycle test machines, environmental test machines, shock testers, rubber testers, plastic test machines, rubber-like cryogenic test machines, grinding testers, melting indexors, flush machines and density meters, thickness gauges, sulfur transformers, etc., and welcomes a wide selection of customers。
