The world-renowned semiconductor rohm, based in kyoto, japan, announced today the launch of the three-way reverse circuit reference designs “ref 68005”, “ref 6806” and “ref 68004” on the official web, which are on board the ecosictm brands of the sic plastic seal modules “hsdip 20”, “dot-247”, “tradrive packtm”. The designer could use this release of reference design data to create a drive circuit board, which could be combined with the sic module of rohm and reduce the design cycle of the actual equipment assessment。
In the conversion of circuits with high power, while the sic power metrware contributes to efficiency and reliability, the time required for outer circuit design and thermal design tends to increase. The rohm-issued reference design can cover an output power range of up to 300 kw and support the use of sic power modules in a wide range of applications such as vehicle-borne equipment and industrial equipment。
Three sic modules that can be used in conjunction with this reference design are available for sale on the electrician platform, which can be purchased through ameya360 and oneyac。
♪ about reference design ♪
※reference design is designed for user development using publicly available design data. For reference design boards or assessment packages, contact the rahm sales representative or “contact us” via the rahm network. (limited quantities)
Simulation support
In order to accelerate product assessment and application, rohm also provides a variety of support resources to support product selection by users through a wealth of solutions, including simulation and thermal design。
Users can download the various design data associated with the evaluation panels from reference design pages, as well as information on the sic module products that can be used in conjunction with reference design pages。
In addition, the system-level validation can be carried out from the metaware selection phase using rohm solution simulator, a simulation tool provided by the rohm official network。
Hsdip20: reference design / rohm solutions simulator / lt spice circuit model
Dot-247: reference design / rohm solutions simulator / lt spice circuit model
Trcdrive packtm: reference design
