Case name: maintenance of the electrical seat control module of the land rover vein (l560)
Car configuration: 2021 land rover veins (l560) equipped with advanced electric seats and advanced electronic vehicle systems。
Fault: the owner reflects the failure of the vehicle's electric seat to properly adjust, the failure of the control button operation and the failure of the seat memory function。
Maintenance:
Fault diagnosis: using road chart 2019-2020 of the land rover pulse (l560), the connection diagnostic device reads the vehicle failure code and the electric seat control module reports “communication failure”. Control module inspection: the electric seat control module is checked for damage or need to be reprogrammed according to the circuit chart. Communication circuit inspection: check the communication lines of the electric seat control module to ensure that there is no break or short circuit, with reference to the road chart 2019-2020 of the land rover pulse (l560). Control module replacement or replacement: if the control module is damaged, replacement is done in accordance with the guide to the circuit chart; if reprogramming is required, programming is done using specialized equipment. System testing: after replacing the control module or updating the software, perform a functional test of the electric seat control system to ensure that the control buttons are back to normal and the seat memory function is back to normal. Road test certificates: a road test with the owner of the vehicle to confirm that the electric seat is modulated and that failure does not recur。
Summary of cases:
Electric seat control problems may be caused by control module failures or communication lines. The maintenance will require a combination of circuit charts and a full inspection and maintenance of the electric seat control system. The replacement of control modules and the inspection of communication lines are important steps in addressing the issue of electric seat control. Systems testing and road test certificates are important elements in confirming the effects of maintenance and need to ensure the comfort and safety of vehicles。
