Maintenance secret, laser printer maintenance guidance
Content navigation:
Eppson laser printer maintenance code
Page 1: eppson laser printer maintenance code 2: hp colour stress failure elimination method 3: colour laser printer general error code detail 4: hp colour heat universal 3) check ps1307 for normal working and replacement of sensor if necessary
13,10 paper jam is printed paper delayed or stuck in a paper-smoking area
(i) checking paper delivery parts for barriers
2) check the repositioning of ps1701, ps1703 sensors in paper senders and, if necessary, replace related sensors
5 / 17
13,20 paper jam or 13,21 paper jam is a print paper that is stuck on a paper path or a printer that is opened。
(i) check the entire path of the paper and remove the obstacles
2) checks whether all paper-release parts are re-located (including cover or not)
3) checking for repositioning of all sensors on the paper path and replacing them if necessary
20 insuffieent memory is the printer that accepts too much data, which is beyond the printer memory。
Disable method 1) press the button to continue printing (part print may be lost)
2) increased printer memory
21 page too comlex is too complex to print。
Release: 1) press the button to continue printing (some print may be lost)
2) set page protect values to auto
22 eioХbuffer overflow is the data sent to the specified eio external。
Release method: press the button to remove this message (the data transmitted will also be lost)
13,5 paper jam or 13,6 paper jam is printed paper that has been delayed or stopped in the heating component。
(i) determines that reprinting and transfer belts work properly
2) determine that there are no obstacles to the path of the paper
3) check ps1307 for normal operation and replace this sensor if necessary
13,10 paper jam is printed paper that is delayed or jammed in the paper-suction area。
(a) dismantling method 1) checks paper delivery parts for barriers
2) check the repositioning of ps1701, ps1703 sensors in paper senders and, if necessary, replace related sensors
13,20 paper jam or 13,21 paper jam is a print paper that is stuck on a paper path or a printer that is opened。
(i) check the entire path of the paper and remove the obstacles
2) checks whether all paper-release parts are re-located (including cover or not)
3) checking for repositioning of all sensors on the paper path and replacing them if necessary
20 insuffieent mamory is a printer that accepts too much data and is beyond the printer memory。
Release method: 1) press the button to continue printing (part print may be lost)
2) increased printer memory
21 page too comlex is too complicated to print。
Release method: 1) press the button and continue printing (some print content may be lost)
2) set page protect values to auto
6/ 17
22 eioХbuffer overflow is the data sent to the specified eio external。
Disable by pressing the button to remove this message (the data transmitted will also be lost)
41,3 unexpected paper size is not matched by print paper type settings。
Release method: set the type of printed paper correctly
50,* fuser error is a heating component error whose value* is as follows:
1 low heating temperature
2 preheat protection for heated components
3 high heating temperature
4. Power pressure instability
5 thermal component does not match
Disable method: 1, turn off the power, 20 minutes to turn on
2. Re-installation of heating components
3, turn off the power supply, remove heating components, and check that j 1307-1 and j 1307-2 and j 1308-1 and j 1308-2 are connected and, if not, replace the other heat components。
51,* printer error is a laser scanning error, and * values are as follows:
1 laser detection error
2 laser error
Release: 1 restart
Re-installation of lasers and associated cables
3. Replacement of lasers
Error code* printer error's failure summary
52,* printer error is not matched by laser scan speed,* the value being as follows:
1 scan start error
